RSLP-G Spring-Balanced Ladder Post is designed for safe entry and exit
assistance from roof hatch or floor door in an upright and balanced position.
Safety post comes fully assembled, ready for installing onto fixed vertical
ladder rungs.
One-handed raising and lowering of the post allows the operator to keep the
other hand on the ladder for safety. Positive mechanical latch with quick
release secures post in the upright position. Adjustable mounting fits rung
spacing up to 14”.
SPECIFICATIONS:
Post Material: Heavy wall square tubing:
1-½" x 1-½" steel
Finish: Hot dip galvanized
Spring Type: Constant force
balancing stainless steel spring
Hardware Included: 316 stainless steel
bolts and washers
Weight: 23 lbs.
Ladder Requirements: Round or square
rungs in sizes 3/4” - 1-¼” spaced between 10"-14" apart
SAFETY NOTES: A Safety Rail System is recommended in
addition to the RSLP Safety Post for greater safety.
Important: Use top
loop for raising and pulling up the post only.
It is not suitable for attaching a
safety fall arrest harness and should not be used for this purpose.
JL Industries a division of Activar Construction Products Group, Inc. Model
RSLP-G
