  • Cannot Rust
  • Easily Cleaned
  • Natural Ventilation
  • Pitched Drainage
  • Dent Proof
  • Fire Retardant
  • Easy Installation
  • No Padlock Required
  • No Glass to Shatt
  • No Paint to Fade or Chip
  • All Sizes in Red or White
  • No Sharp Corners
  • High Density Injection Molded Hammer (optional above)
  • Stainless Steel Breaker Bar (optional above)
  • Felony Warning Decal CL-416 (optional above)
  • Made in the U.S.A.

CATO 12001-H Chief Plastic 20 lbs. Fire Extinguisher Cabinet - White

Description

The CATO 12001-H Chief plastic 20 lbs. fire extinguisher cabinet in red is design to hold a 20 lbs. fire extinguisher.  Because there are no metal parts, this cabinet can not rust.  This CATO cabinet has a built-in extinguisher tray to separate the extinguisher from moister at the bottom of the cabinet.

The CATO 12001 fire extinguisher cabinet, also know as the CATO PC 105-20 WWC, is manufactured by Cato, Inc. with body and frame injection molded white virgin high-impact crystal polystyrene of .110 wall thickness with ultra-violet inhibitors, virgin acrylic Plaskolite® panel of .80 thickness, ABS lock and key, polypropylene plastic injected molded hammer with flexible torsion, ribbed grip surface and clear nylon-jacketed stainless steel mechanical cable (optional above).  Stainless steel breaker bar (optional above).

  Technical Data   Catalog

Made in USA

    Warranty

Available Sizes

Lock & Key
The all-plastic ABS cam lock and key eliminates corrosion making the CATO Chief the first cabinet with a non-seize lock.  This lock will never rust.

Hammer
White injection molded plastic hammer with flexible torsion and ribbed grip with a stainless steel clear nylon jacketed mechanical cable used to break the clear acrylic panel in case of fire (optional above).

Breaker Bar
Stainless Steel Breaker Bar with a stainless steel clear nylon jacketed mechanical cable used to break the clear acrylic panel in case of fire (optional above) .

Safety
With no sharp corners or breakable glass, the Chief Plastic Fire Extinguisher Cabinet is one of the safest cabinets available.

Plastic Fire Extinguisher Cabinets Dimensions

Model # Interior Tub Overall Outside Trim With Cover Outside
  W H D W H D W H D
Plastic Fire Extinguisher Cabinets
CA-10501 6" 16 3/4" 5 3/8" 8" 19" 6 3/8" 8 1/4" 19 1/4" 6 3/4"
CA-11001 6 3/4" 20 1/2" 6" 9" 23" 7" 9 1/4" 23 1/4" 7 1/4"
CA-12001 9" 26" 8" 11" 28" 9" 11 1/2" 28 1/2" 9 1/2"



Alternate Part Numbers
PC-105 Red CATO Chief
PC-105-5 (WWC) 10501
PC-105-10 (WWC) 11001
PC-105-20 (WWC) 12001



Compare to:

  • Strike First PC-105-20
  • Brooks FT20PW  FireTech™

Cato 12001-H
