The CATO 12001-H Chief plastic 20 lbs. fire extinguisher cabinet in
red is design to hold a 20 lbs. fire extinguisher. Because there are no metal
parts, this cabinet can not rust. This CATO cabinet has a built-in
extinguisher tray to separate the extinguisher from moister at the bottom of the
cabinet.
The CATO 12001 fire extinguisher cabinet, also know as the CATO PC
105-20 WWC, is manufactured by Cato, Inc. with body and frame injection molded
white virgin high-impact crystal polystyrene of .110 wall thickness with
ultra-violet inhibitors, virgin acrylic Plaskolite® panel of .80 thickness, ABS
lock and key, polypropylene plastic injected molded hammer with flexible
torsion, ribbed grip surface and clear nylon-jacketed stainless steel mechanical
cable (optional above). Stainless steel breaker bar (optional
above).
Available Sizes
Lock & Key
The all-plastic ABS cam lock and key eliminates
corrosion making the CATO Chief the first cabinet with a non-seize lock. This
lock will never rust.
Hammer
White injection molded plastic hammer with flexible torsion and ribbed grip with a stainless steel clear nylon jacketed mechanical cable used to break
the clear acrylic panel in case of fire (optional above).
Breaker Bar
Stainless Steel Breaker Bar with a stainless steel clear nylon jacketed mechanical cable used to break
the clear acrylic panel in case of fire (optional above) .
Safety
With no sharp corners or breakable glass, the Chief Plastic Fire Extinguisher Cabinet is one of the safest cabinets available.
Plastic Fire Extinguisher Cabinets Dimensions
Model # |
Interior Tub |
Overall Outside Trim |
With Cover Outside |
|
W |
H |
D |
W |
H |
D |
W |
H |
D |
Plastic Fire Extinguisher Cabinets |
CA-10501 |
6" |
16 3/4" |
5 3/8" |
8" |
19" |
6 3/8" |
8 1/4" |
19 1/4" |
6 3/4" |
CA-11001 |
6 3/4" |
20 1/2" |
6" |
9" |
23" |
7" |
9 1/4" |
23 1/4" |
7 1/4" |
CA-12001 |
9" |
26" |
8" |
11" |
28" |
9" |
11 1/2" |
28 1/2" |
9 1/2" |
Alternate Part Numbers |
PC-105 Red |
CATO Chief |
PC-105-5 (WWC) |
10501 |
PC-105-10 (WWC) |
11001 |
PC-105-20 (WWC) |
12001 |
Compare to:
- Strike First PC-105-20
- Brooks FT20PW FireTech™
Cato 12001-H
